Description
SPECIFICATIONS
IFT
| Mode | 4P, 4PV, 2P & Russian Current |
| Frequency | 2, 3, 4, 5, 6, 7, 8, 9 & 10 kHz |
| Base | 1 to 150 Hz, 1 Hz step |
| Spectrum | 1 to 150 Hz, 1 Hz step, LIN, NL & TRP shape |
| Vector Type | 2PL, 4PL, 4PT & 4PNL |
| Output | Isolated 0–98 mA |
UST
| Frequency | 1 MHz |
| Mode | Continuous & Pulse modes (1:1 to 1:16) |
| Power Output | 0 to 3.1 W/cm² |
| Timer | 1–30 minutes, adjustable |
| Input Power | SMPS @ 150–275V AC, 50 Hz |
| Dimensions | 310 × 220 × 90 mm |
| Weight | 2.9 kg |
