Description
SPECIFICATIONS
| Therapy Modes | Faradic, Surge Faradic, Galvanic, Interrupted Galvanic, U- Reiz, HVPC, Micro Current & TENS |
| TENS | |
| Mode
Frequency Burst period
Output |
Continuous & Burst
1 to 150 Hz @ 25 to 400 µs ON time adjustable Hold & Rest : 1-6 sec adjustable 0 – 100 mA |
| Stimulator | |
| Faradic
Surge Faradic Interrupted Galvanic |
0.7mS ON time @20mS period
Faradic @ Hold & ON time : 0.01,.03,0.1,0.3,1,3,10,30,100,300&1000 ms Rest : 1 to 6 sec adjustable |
| Output Intensity | 0 – 100mA |
| Timer | 1 to 30 min adjustable |
| Power Supply | SMPS @ 100V–275VAC, 50Hz |
| Dimension | 185 x 205 x 90 mm |
| Weight | 1.75 Kg |
